Front Panel View of The Power Supply. The Decals Were Made With Paint Shop Pro.
Overall inside View of The Supply From The Back
A closer Overall Inside View of The Supply From The Back
A Close Up Look At The Right Side of The Supply From The Back Showing The Rectifier, And Capacitor Board, The Filament and Control Voltage Transformer, an The Control Voltage regulator, and filter Board For The Relays.
A Look From The Back of The Supply Showing The Connections For Three Amps.
A Look At The Completed Supply From The Back Showing The Case That I Made From Stuff That I Got From Home Depot, Except For The Chassis. The Front Panel Is A 10 X 19 inch Rack Mount Panel With Handles.
